CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W
![CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [1]](https://gomagcdn.ro/domains/electrofive.ro/files/product/original/standard-dc-dc-converter-input-dc-24v-output-dc-24-28v-10a-240w-copie-1163-1589.jpg "CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [1]")
![CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [2]](https://gomagcdn.ro/domains/electrofive.ro/files/product/original/standard-dc-dc-converter-input-dc-24v-output-dc-24-28v-10a-240w-copie-1163-9564.jpg "CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [2]")
![CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [3]](https://gomagcdn.ro/domains/electrofive.ro/files/product/original/standard-dc-dc-converter-input-dc-24v-output-dc-24-28v-10a-240w-copie-1163-3012.jpg "CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [3]")
![CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [0]](https://gomagcdn.ro/domains/electrofive.ro/files/product/medium/standard-dc-dc-converter-input-dc-24v-output-dc-24-28v-10a-240w-copie-1163-1589.jpg "CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [0]")
![CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [1]](https://gomagcdn.ro/domains/electrofive.ro/files/product/medium/standard-dc-dc-converter-input-dc-24v-output-dc-24-28v-10a-240w-copie-1163-9564.jpg "CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [1]")
![CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [2]](https://gomagcdn.ro/domains/electrofive.ro/files/product/medium/standard-dc-dc-converter-input-dc-24v-output-dc-24-28v-10a-240w-copie-1163-3012.jpg "CD10.242, standard DC/DC Converter, Input: DC 48V, Output: DC 24-28V, 10A, 240W [2]")
General specifications
- 48V DC-input
- Isolated 48Vdc output
- Efficiency 95.1%
- Width only 42mm
- 20% output power reserves
- Full power between -25°C and +60°C
- Soft-start function
- Minimal inrush current surge
- Reverse input polarity protection
DC Output
- 24-28Vdc
- 10-8.6A
- 240W
Input
- AC 100-240V
- DC 110V-300V
- Size (WxHxD): 39 x 124 x 117mm
- Weight 500g
Durata de livrare: 2 saptamani
- Descriere
- Video (1)
- Review-uri (0)
The CD10.241 is a DIN-rail mountable DC/DC converter of the DIMENSION series which provides a floating, stabilized and galvanically separated SELV/PELV output voltage. The CD-Series is part of the DIMENSION power supply family.
The most outstanding features of CD10.241 are the high efficiency, the small size and the wide operational temperature range.
The CD-Series includes all the essential basic functions.
The devices have a power reserve of 20% included, which may even be used continuously at temperatures up to +45°C.
High immunity to transients and power surges as well as low electromagnetic emission and a large international approval package for a variety of applications makes this unit suitable for nearly every situation.
