CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W
![CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [1]](https://gomagcdn.ro/domains/electrofive.ro/files/product/original/puls_cd10_482_m_300dpi-1164-38508742.jpg "CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [1]")
![CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [2]](https://gomagcdn.ro/domains/electrofive.ro/files/product/original/standard-dc-dc-converter-input-dc-48v-output-dc-48-56v-5a-240w-1164-58105679.jpg "CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [2]")
![CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [3]](https://gomagcdn.ro/domains/electrofive.ro/files/product/original/standard-dc-dc-converter-input-dc-48v-output-dc-48-56v-5a-240w-1164-53626671.jpg "CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [3]")
![CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [0]](https://gomagcdn.ro/domains/electrofive.ro/files/product/medium/puls_cd10_482_m_300dpi-1164-38508742.jpg "CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [0]")
![CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [1]](https://gomagcdn.ro/domains/electrofive.ro/files/product/medium/standard-dc-dc-converter-input-dc-48v-output-dc-48-56v-5a-240w-1164-58105679.jpg "CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [1]")
![CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [2]](https://gomagcdn.ro/domains/electrofive.ro/files/product/medium/standard-dc-dc-converter-input-dc-48v-output-dc-48-56v-5a-240w-1164-53626671.jpg "CD5.051, standard DC/DC Converter, Input: DC 24V, Output: DC 5-5.5V, 10A, 50W [2]")
General specifications
- 24V DC-input
- Isolated 48Vdc output
- Efficiency 95.1%
- Width only 32mm
- 20% output power reserves
- Full power between -25°C and +60°C
- Soft-start function
- Minimal inrush current surge
- Reverse input polarity protection
DC Output
- 5-5.5Vdc
- 10A
- 50W
Input
- DC 18V-32.4V
- Size(WxHxD) 32 x 124 x 102mm
- Weight 425g
Durata de livrare: 2 saptamani
- Descriere
- Video (1)
- Review-uri (0)
The CD10.241 is a DIN-rail mountable DC/DC converter of the DIMENSION series which provides a floating, stabilized and galvanically separated SELV/PELV output voltage. The CD-Series is part of the DIMENSION power supply family.
The most outstanding features of CD10.241 are the high efficiency, the small size and the wide operational temperature range.
The CD-Series includes all the essential basic functions.
The devices have a power reserve of 20% included, which may even be used continuously at temperatures up to +45°C.
High immunity to transients and power surges as well as low electromagnetic emission and a large international approval package for a variety of applications makes this unit suitable for nearly every situation.
